Large Ride-on Combination Machine Scrubber Sweeper JIECHI M17

Home Products Combination Machine

Large Ride-on Combination Machine Scrubber Sweeper JIECHI M17

Large Ride-on Combination Machine Scrubber Sweeper JIECHI M17

The JIECHI M17 is a professional floor scrubber designed for large hard-floor areas where efficient and consistent cleaning is required. Its integrated scrubbing and water recovery system helps remove dust, dirt, footprints, stains and everyday floor contamination in one operation.The M17 is ideal for industrial workshops, warehouses, logistics centers, supermarkets, shopping malls, parking garages and large commercial facilities.

Designed for practical daily operation, it helps reduce repetitive manual cleaning, improve cleaning productivity and keep floors cleaner and drier after each pass.

  • Model :

    M17
  • Voltage :

    36V/460Ah
  • Cleaning Width :

    1060mm
  • Suction Width :

    1400mm
  • Performance :

    8600㎡/h
  • Traction Motor :

    1500W
  • Brush Motor :

    800W*2
  • Lifting Motor :

    100W*2
  • Suction Motor :

    650W*2
  • Solution Tank :

    300L
  • Recovery Tank :

    350L
  • Size :

    223*124*148cm
  • Weight :

    1525kg



The JIECHI M17 is a flagship adaptive heavy-duty cleaning machine designed for high-standard and high-difficulty industrial refined cleaning scenarios. Breaking through the limitations of fixed chassis and insufficient cleaning power of ordinary integrated cleaners, it adopts an intelligent height-adjustable chassis, high-torque heavy-duty roller brush, and high-precision water circulation system. It specializes in removing cured oil stains, thick accumulated dust, and complex mixed dirt that cannot be handled by ordinary models. With superior adaptability for multi-material spliced and slightly undulating hard floors, it is the preferred professional equipment for high-end industrial parks, large logistics hubs, and refined municipal sanitation projects.



Where It Works Best

Internal and external passages of high-standard industrial parks|large logistics freight hubs, refined municipal hard roads|super commercial complexes|high-end parking lots and standardized hard service areas of scenic spots
  • #
  • #
  • #



Core Engineering & Operational Advantages


  • Flagship Heavy-Duty Cleaning to Remove Stubborn

    Industrial Dirt Equipped with an upgraded high-torque power assembly and heavy-duty roller brush matched with a high-pressure water supply system, the machine features greatly enhanced dirt stripping capacity. It effectively eliminates long-term cured industrial oil stains, thick dust deposits and heavy mixed impurities, solving stubborn cleaning problems that cannot be handled by ordinary cleaning equipment.



  • Self-Adaptive Chassis for Full Complex Working

    Conditions Built with an intelligent height adjustment chassis and integrated anti-collision structure, it automatically fits slightly undulating ground and multi-material spliced pavements, and intelligently calibrates the cleaning height and fitting degree. It realizes both high-precision indoor fine floor scrubbing and high-intensity outdoor large-area cleaning, avoiding dirt residue and chassis collision damage caused by fixed chassis defects.



  • Support Long-Term High-Intensity Operation

    Adopting an enhanced industrial maintenance-free battery, the machine supports all-weather high-intensity continuous operation. The whole machine adopts waterproof, dustproof and anti-corrosion three-proof technology with excellent wear and collision resistance and long service life, which greatly reduces the comprehensive operation and maintenance cost in high-load industrial and municipal scenarios.





Suitable Floor / Surface Types


It is fully applicable to high-standard hard floors, including high-precision epoxy floors, non-slip tile floors, cured cement floors, asphalt roads, concrete roads and regular brick pavements. It is not suitable for severely uneven ground, loose gravel roads, soft carpets and non-hard landscape ground.


Maintenance & Daily Operation



After each high-intensity operation, thoroughly empty all garbage and sewage to prevent stubborn dirt from drying and adhering. Deeply clean residual dirt in roller brush gaps and on the contact surface of squeegee blades to avoid dirt accumulation affecting refined cleaning results. Regularly inspect battery performance, the flexibility of the adaptive chassis and the unobstructed state of pipelines, and replace worn consumables in a timely manner.





Technical Specifications

M17

Voltage 36V/460Ah Suction Motor 650W*2
Cleaning Width 1400mm Water Tank 300L/350L
Brush Motor 800W*2 Traction Power 1500W
Lifting Motor

100W*2

Area Performance 8600m²/h
Machine Size 223*140*148cm Machine Weight 1525kg


FAQ

What is the upgrade advantage of M17 compared with ordinary integrated machines?

M17 has upgraded power and cleaning structure, with stronger ability to clean stubborn stains and large-particle sundries, and wider scenario adaptability, realizing higher-standard composite cleaning.

Can it switch freely between indoor and outdoor use?

Yes. The equipment is optimized for dual-scenario use, which can freely switch between indoor refined washing and outdoor sanitary sweeping with stable cleaning effect.

What is the service life of M17 consumables? Is the replacement cost high?

The M17 adopts custom widened industrial heavy-duty roller brushes with high wear resistance, which adapts to long-term severe industrial working conditions. Its main consumables are conventional roller brushes and squeegee blades with no hidden high maintenance costs. The consumables feature strong universality and low procurement cost, achieving extremely high cost performance in long-term operation.
